Welcome to AADITYA!
All “AADITYA” transformers are type tested & certified from Internationally accredited & reputed 3rd party test houses such as CPRI as per IEC 60076, ISS 2026, ISS 1180 & ISS 335 norms.
All “AADITYA” Transformers are designed using CAD techniques in conformance with IS, IEC or ANSI standards.What sets us apart?
Sophisticated manufacturing equipment such as Air Drying Oven,Variable Frequency Drive Winding Machines in order to ensure product reliability.
In-house facility for Core assembly, Oil storage and filtration, using latest machineryfor QC and JIT approach.
Material handling facilities such as EOT Crane, Pneumatic trolleys and an innovative plant layout for easy and fast movement of components during manufacturing.
Sophisticated and calibrated testing equipment for in-house Routine and Type Tests.
Strict Quality control for incoming stock, process monitoring and finished products utilizing a Manufacturing Quality Plan process.
What sets our transformers apart?
High-energy efficient wound core transformers are made from amorphous metal along with electrolytic grade copper or with aluminum if requested by the customer.
Conventional stacked core Transformers are made from Prime grade CRGO steel with electrolytic grade copper or aluminum, depending on the customer requirement.
Circular cores are formed from prime grade Amorphous metal or CRGO steel to ensure a low loss. Annealing of the formed cores is done under inert atmosphere to ensure stress release from the cores, thereby retaining the original characteristic of electrical steel.
Accurately wound LV and HV windings ensure the short circuit withstand ability of the Transformer whilst proper drying along with right grade of insulation ensures the capacity to withstand the specified impulse level.
HV and LV coils are prepared in a near dust free environment and are subjected to regular process checks.
HV coils are designed in order to
Ensure effective uniform distribution of voltage to reduce impulse and transient forces
Compression of coils for proper geometrical shape is in order to minimize axial forces during short circuit condition.
The Core-Coil Assembly (also known as the active part) is processed under controlled conditions in an air-drying oven to ensure removal of moisture while preventing insulation damage on account of excessive heating, thus increasing the productive life of the transformers.
Our Vision
To be one of the most respected, path breaking & quality conscious companies in its segment, having one of the highest efficiency & advances in technology in its products & operations.
Our Mission
To create a efficient manufacturing company driven on quality & value for money pricing in order to deliver the best possible product in each segment, to the customer
Why Choose Us
Long lasting, energy efficent, high build quality transformers with a wide range of options.
"NEED WE SAY MORE ?!" -
AADITYA’s Products
High Efficiency Amorphous Core 5, 4 & 3 Star Rated Distribution transformers in accordance with BEE's Energy Labelling programme.
Single phase wound core transformers Up to 100 kVA in the Voltage class: 6KV & 11 KV.
Three Phase Stacked & Wound Core Distribution Transformers
Up to 1.50mVA in the Voltage Class: 6kV and 11kV.
Upto10mVA in the Voltage Class: 33 kV.
Special Purpose Transformers for Industrial &Commercial Requirements.Standard & Optional Fittings
Each “AADITYA” brand transformer has the following standard fitments:
Pole Mounting Brackets/Tanks
Base Channels
Lifting LugsTesting
All transformers are dispatched only once they pass the following tests:
Ratio, Polarity, Phase Sequence & Winding Resistance Test
No-Load Loss & Excitation
Current Measurement Test.Technical Specifications
Ratings
CRGO - Upto 2500 kVA
AMT - Upto 1000 kVAApplicable
StandardsIS, IEC, ANSI, JIS, BS etc.
Benefits of Amorphous Core
In order to understand the advantage of an Amorphous Core, first we should understand the two types of Losses in a transformer:
Load Losses Or Coil Losses: the
loss is proportional to the square of load drawn.Benefits of Amorphous Metal Transformer
No load losses are 70% to 80%
lesser when compared to
conventional transformers.
A payback period of less than
3 years, after which the benefits
continue for the life of the
product.Copper Vs Aluminum
In electrical transformers wound with aluminum or copper coils have similar losses and performance. Losses in the transformer’s coil are a function of the current carrying capacity of the wire or strip used to wind them and the actual input of current.
-
Standard & Optional Fittings
Each “AADITYA” brand transformer has the following standard fitments:
Standard & Optional Fittings
Each “AADITYA” brand transformer has the following standard Fitments:
Pole Mounting Brackets/Tanks Base Channels
Lifting Lugs
Tank Grounding/ Earthing Provision
Pressure Relief Vent
Thermometer Pocket
Drain Valve
Rating and Diagram Plate
Primary Bushings
Secondary Bushings
Each “AADITYA” brand transformer has the following Optional Fitments:
Mounting arrangement options:
Uni / Bi-directional Rollers
Side/Bottom mounts.Tank type options:
Conventional (Bolted)
Corrugated.Radiator options:
Conventional
Flange bolted/ Welded.Surface Treatment options:
Painted: as per as requirements for different atmospheric conditions.
Powder Coated
Galvanized.Connections:
Bushings.
Cable Boxes.
On Load/ Off Circuit Tap Changers/Switch. -
Testing
All transformers are dispatched only once they pass the following tests:
Testing
All transformers are dispatched only once they pass the following tests:
Ratio, Polarity, Phase Sequence & Winding Resistance Test
No-Load Loss & Excitation Current Measurement Test.
Load Loss & Impendence Measurement Test
Insulation Resistance Test
Separate source voltage withstand test
Induced over voltage withstand test
Transformer Oil Dielectric Strength Test
-
Technical Specifications
Each “AADITYA” brand transformer has the following standard fitments:
Technical Specifications
Each “AADITYA” brand transformer has the following standard fitments:
Ratings
CRGO - Upto 2500 kVA
AMT - Upto 1000 kVAApplicable Standards
IS, IEC, ANSI, JIS, BS etc.
Cooling
ONAN, OA
Insulating Fluid
Mineral Oil to specification
Frequency
50 Hz, 60 Hz
Polarity
As specified
Primary voltage
Upto 33 kV
Secondary Voltage
415, 433 V (Other Voltages as required)
Winding material
Copper / Aluminum
Taping range
± 5% in steps of 2.5% (Other tapings as required)
Impedance
In line with applicable standards
-
Benefits of Amorphous Core
In order to understand the advantage of an Amorphous Core, first we should understand the two types of Losses in a transformer:
Benefits of Amorphous Core
In order to understand the advantage of an Amorphous Core, first we should understand the two types of Losses in a transformer:
Load Losses Or Coil Losses: the loss is proportional to the square of load drawn.
No Load Losses Or Core Losses: the loss is continuous, independent of load.
Amorphous metal helps us minimize the No Load Losses that translates into High Saving Potential
The various no load losses:
Hysteresis Loss: The random molecular structure of amorphous metal ensures lesser friction than CRGO silicon steel, when a magnetic field is applied. This unique property of this metal ensures a faster magnetization & demagnetization, thus significantly lowering hysteresis losses in amorphous metals.
Eddy Current Loss: Amorphous metals have very thin laminations. Thin laminations result in lower eddy current losses when compared to CRGO silicon steel. -
Benefits of Amorphous Metal Transformer
Benefits of Amorphous Metal Transformer
No load losses are 70% to 80% lesser when compared to conventional transformers.A payback period of less than 3 years, after which the benefits continue for the life of the product.
Fast & easy repair due to modular construction
High reliability & Excellent Short Circuit Capability:
Robust single coil construction addresses axial component of short circuit forces.
Interlayer bonding using epoxy dotted paper addresses radial component of short circuit forces.
Better Overloading Capacity:
Lesser heat generation due to lower losses, thus lesser impact on aging of insulation.
Assured Product Quality: Use of single quality (grade) core material.
Last but not the least: a significant contribution to the green footprint by the reduction of the no-load losses.
-
Copper Vs Aluminum
Copper Vs Aluminum
In electrical transformers wound with aluminum or copper coils have similar losses and performance. Losses in the transformer’s coil are a function of the current carrying capacity of the wire or strip used to wind them and the actual input of current. Therefore, a Larger wire or strip is used when winding aluminum coils to make up for the lower current carrying capacity and efficiency of aluminum.
Aluminum wound coils are larger than an equivalent copper coil. In applications requiring very tight transformer dimensions, a copper coil transformer is suggestible. Aluminum wire requires approximately 1.6 times as much Cross section as copper to carry an equivalent amount of current.
Copper has a higher tensile strength than aluminum. Thin aluminum wire is brittle. Smaller transformers, generally 16 kVA and under are wound with copper to avoid snapping or damaging the wire during winding. Copper wire is more flexible and smaller than aluminum wire.
Certain high efficiency applications can also be more economically achieved using copper units, where larger wire sizes can cause more losses.
Aluminum transformers tend to be less costly than copper transformers. A kilo of aluminum has about twice the current carrying capacity of cropper but costs ½ to ¼ as much.
Since both aluminum and copper transformers use the same insulation systems andhave similar temperature rises, due to which they have similar lifetime ratings. -
Why Us
LONG LASTING, ENERGY EFFICENT, HIGH BUILD QUALITY TRANFORMERS WITH A WIDE RANGE OF OPTIONS.
"NEED WE SAY MORE ?!"Where to Find Us:
